AFBR-5302Z

Broadcom Limited
RoHS
/
Package SIP
Category Optoelectronics / Fiber Optics - Transceiver Modules
Description Fiber Optic Transmitters, Receivers, Transceivers SC 1X9 Transceiver
PDF
/
Inventory: 8728
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Body Height 10.35mm

Technical

Return Loss-Min 3 dB
Optical Power Output-Nom 0.014mW
Emitter/Detector Type LED, PIN PHOTODIODE
Operating Wavelength-Nom 1325 nm
Built-in Feature AMPLIFIER
Fiber Type 50/125, MMF
Wavelength 1308nm
Data Rate 25Mbps
Operating Supply Voltage 5V
Max Output Current 50mA
Body Breadth 25.4 mm
Supply Voltage 5V
Voltage - Supply 4.75V~5.25V
HTS Code 8517.62.00.50
Additional Feature IT CAN ALSO OPERATE AT 1280 TO 1380 NM
Applications General Purpose
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Connector Type SC
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Published 2006

Physical

Number of Pins 9
Package / Case SIP
Mounting Type Through Hole
Mount Through Hole
