PLT153/K5H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Optoelectronics / Fiber Optics - Receivers
Description
RECEIVER FIBER OPT IR PHOTOLINK
PDF
/
Inventory: 1739
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Technical
Published 2005
Series Photolink
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Connector
Max Operating Temperature 70°C
Min Operating Temperature -20°C
Applications Digital Audio
Additional Feature IT ALSO OPERATES FOR 5V SUPPLY
Voltage - Supply 2.75V~3.25V 4.75V~5.25V
Supply Voltage 3V
Body Breadth 12.3 mm
Operating Supply Voltage 5V
Current - Supply 10mA
Data Rate 16Mbps
Wavelength 660 nm
Fiber Type 980/1000, POF
Fiber Optic Device Type TRANSMITTER
Operating Wavelength-Nom 660 nm
Emitter/Detector Type LED
Optical Power Output-Nom 0.0158mW
Power - Minimum Receivable -21dBm
Dimensions
Body Height 19.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
