HFBR-2316TZ
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Optoelectronics / Fiber Optics - Receivers
Description
AVAGO TECHNOLOGIES HFBR-2316TZ FIBRE OPTIC MODULE
PDF
/
Buying Options
Total Price: USD $77.86
Unit Price: USD $77.85915
≥1 USD $77.85915
≥10 USD $63.88465
≥100 USD $61.88775
≥500 USD $59.8918
≥1000 USD $57.89585
≥3000 USD $51.9061
Inventory: 1018
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 12.6mm
Length 29.8mm
Height 10.2mm
Technical
Reception Type ANALOG
Power - Minimum Receivable -45dBm
Communication Standard OC-3, SONET
Connection Type ST CONNECTOR, SC CONNECTOR
Emitter/Detector Type LED
Operating Wavelength-Nom 1300 nm
Built-in Feature AMPLIFIER
Fiber Optic Device Type RECEIVER
Fiber Type 9/125, 50/125, 62.5/15, MMF, SMF
Wavelength 1.3μm
Fall Time (Typ) 5.3 ns
Rise Time 5.3ns
Data Rate 155Mbps
Output Current 25mA
Operating Supply Current 15mA
Operating Supply Voltage 5V
Max Output Current 25mA
Supply Voltage 5V
Voltage - Supply 4.75V~5.25V
Subcategory Fiber Optic Receivers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2008
Physical
Number of Pins 8
Package / Case Module
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
