AFBR-2408Z
RoHS
RoHS compliant
RoHS compliantPackage SMA
Category Optoelectronics / Fiber Optics - Receivers
Description
Fiber Optic Transmitters, Receivers, Transceivers RX DC-50MBd ML 820nm SMA
PDF
/
Buying Options
Total Price: USD $28.49
Unit Price: USD $28.4856
≥1 USD $28.4856
≥10 USD $22.30287
≥100 USD $19.48144
Inventory: 264
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 12.7mm
Length 22.2mm
Height 10.2mm
Technical
Responsivity 0.72 A/W
Reception Type DIGITAL
Power - Minimum Receivable -24dBm
Emitter/Detector Type PHOTODIODE
Operating Wavelength-Nom 820 nm
Fiber Optic Device Type RECEIVER
Fiber Type 50/125, 62.5/125, MMF
Wavelength 820 nm
Fall Time (Typ) 5 ns
Rise Time 5ns
Data Rate 50MBd
Current - Supply 30mA
Operating Supply Voltage 5V
Max Output Current 10mA
Supply Voltage 5V
Voltage - Supply 3.135V~5.25V
Applications Optical
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series AFBR-24x8xZ
Published 2013
Physical
Number of Pins 8
Package / Case SMA
Mount Panel, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
