1963390000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Fiber Optic Connectors
Description
CONN FIBER SC PLUG DUPLX
PDF
/
Inventory: 1370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
Technical
Attenuation - Typ -1.0dB
Boot Color Orange
Mode POF
Simplex/Duplex Duplex
Cable Diameter 10.0mm
Wire/Cable Diameter 10 mm
Mating Cycles 500
Connector Style SC
Coupling Type SNAP
Housing Color Black
Ingress Protection IP67 - Dust Tight, Waterproof
Option GENERAL PURPOSE
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Fastening Type Push-Pull
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Cable Clamp, Strain Relief
Series IE-Line
Published 2008
Operating Temperature -40°C~70°C
Physical
Body Material Zinc Die Cast
Housing Material Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 10 Weeks
