90500-3016
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FFC VERT 16POS 2.54MM PCB
PDF
/
Inventory: 3710
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mounting Type BOARD
Housing Material PBT
Mounting Option 1 FCC RETNN DVC
Actuator Material Glass, PBT, Polybutylene
Mounting Style STRAIGHT
Technical
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 16
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Female
Voltage - Rated 250V
Additional Feature DUAL BEAM CONTACT
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 16
Orientation Vertical
Depth 7.3mm
Current Rating 2.5A
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 1
Lead Pitch 2.54mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.285 inch
UL Flammability Code 94V-0
Housing Color Black
Rated Current (Signal) 1A
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Insulation Resistance 5000000000Ohm
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min .3336 N
Stackable No
Dimensions
Length 53mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
