54132-5092
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors 0.5MM FFC/FPC 50 CKT R/A SMT ZIF
PDF
/
Inventory: 8072
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Nylon
Actuator Material Polyphenylene
Technical
Packaging Cut Tape (CT)
Pbfree Code no
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Number of Rows 1
Gender Male
HTS Code 8536.69.40.51
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 50V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 508μm
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.201 inch
Number Of PCB Rows 1
Lead Pitch 500μm
Number of Contacts 50
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
UL Flammability Code 94V-0
Body Depth 0.197 inch
Rated Current (Signal) 0.5A
Contact Style SINGLE PRONG
Contact Resistance 20mOhm
Insulation Resistance 50MOhm
Wire/Cable Type Straight
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Contact Location Bottom
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
