54104-5092
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors RA SMT ZIF TOP 50P
PDF
/
Inventory: 1096
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold, Tin
Mount Surface Mount
Housing Material Polyamide
Actuator Material Polyphenylene
Technical
Packaging Cut Tape
Pbfree Code no
Termination Solder
Connector Type FFC/FPC CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Number of Rows 1
Additional Feature ZIF
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 50V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 508μm
Current Rating 500mA
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 1.201 inch
Number Of PCB Rows 1
Lead Pitch 500μm
Number of Contacts 50
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Body Depth 0.197 inch
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Contact Resistance 20mOhm
Insulation Resistance 50MOhm
Wire/Cable Type Straight
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Insulator Color BEIGE
Dimensions
Height 2mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
