52806-0570
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Inventory: 3610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length - Termination 0.126 inch
Plating Thickness 4μin
Technical
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 2.0066 mm
Wire/Cable Type Straight
Contact Style BELLOWED TYPE
Body Depth 0.213 inch
Body Breadth 0.118 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Reliability COMMERCIAL
Reference Standard UL
Current Rating 500mA
Reach Compliance Code unknown
Orientation Vertical
Total Number of Contacts 4
Pitch 990.6μm
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Voltage - Rated 50V
Number of Rows 1
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Number of Positions 5
Connector Type FFC/FPC CONNECTOR
Termination Kinked Pin
Physical
Housing Material Polyphenylene
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
