52745-0890

Molex
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description ZIF FFC Connector
PDF
/
Inventory: 6966
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant

Technical

Insertion Force-Max ZIF N
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 250VAC V
Termination Type SURFACE MOUNT
Mating Contact Pitch 0.02 inch
Insulation Resistance 50000000Ohm
Contact Resistance 20mOhm
Rated Current (Signal) 0.5A
Body Depth 0.169 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -20°C
Contact Gender FEMALE
Body Breadth 0.079 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 8
Lead Pitch 500μm
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Terminal Pitch 0.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature ZIF
Number of Rows 1
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Pbfree Code no
Packaging Tape & Reel (TR)

Physical

Mounting Style RIGHT ANGLE
Mounting Option 1 FCC RETNN DVC
Housing Material Nylon
Mounting Type BOARD
Contact Plating Tin
Contact Material NOT SPECIFIED
