52559-2270
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 22 POS 1mm Solder ST SMD Easy-On? Embossed T/R
PDF
/
Buying Options
Total Price: USD $4.01
Unit Price: USD $4.01091
≥1 USD $4.01091
≥200 USD $1.600425
≥500 USD $1.546596
≥1000 USD $1.520338
Inventory: 2973
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Plating Thickness 39μin
Technical
Insulator Color BEIGE
Withdrawl Force-Min ZIF N
Insertion Force-Max ZIF N
Contact Pattern RECTANGULAR
Durability 20 Cycles
PCB Contact Row Spacing 2.794 mm
Wire/Cable Type Straight
Dielectric Withstanding Voltage 250VAC V
Insulation Resistance 50000000Ohm
Contact Resistance 20mOhm
Contact Style SINGLE PRONG
Rated Current (Signal) 0.5A
UL Flammability Code 94V-0
PCB Contact Pattern STAGGERED
Lead Pitch 500μm
Number Of PCB Rows 2
Body Length or Diameter 0.657 inch
Reliability COMMERCIAL
Reference Standard UL
Current Rating 500mA
Total Number of Contacts 22
Pitch 1mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated DC 50V
Subcategory Headers and Edge Type Connectors
Additional Feature ROHS, ELV COMPL & EMBOSSED PKG
Gender Receptacle
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 22
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code yes
JESD-609 Code e6
Published 2011
Packaging Tape & Reel (TR)
Physical
Actuator Material Polyphenylene
Housing Material Nylon
Mount Surface Mount
Contact Plating Tin
Contact Material Bronze
