52559-1072
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FFC VERT 10POS 0.50MM SMD
PDF
/
Buying Options
Total Price: USD $9.4
Unit Price: USD $9.400069
≥1 USD $9.400069
≥10 USD $8.86799
≥100 USD $8.366028
≥500 USD $7.892476
≥1000 USD $7.445737
Inventory: 5632
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Nylon
Actuator Material Polyphenylene
Technical
Packaging Cut Tape (CT)
Published 2004
Pbfree Code yes
Termination Solder
Connector Type FFC/FPC CONNECTOR
Number of Positions 10
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Receptacle
Additional Feature ZIF
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 50V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 500μm
Total Number of Contacts 10
Depth 3mm
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 500μm
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Housing Color Natural
Rated Current (Signal) 0.5A
Contact Style DUAL PRONG
Contact Resistance 20mOhm
Insulation Resistance 50000000Ohm
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Straight
PCB Contact Row Spacing 2.794 mm
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Dimensions
Length 10.7mm
Plating Thickness 39μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
