52437-2472
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FFC BOTTOM 24POS 0.50MM R/A
PDF
/
Inventory: 4648
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Polyamide
Actuator Material Glass, Polyphenylene
Technical
Packaging Tape & Reel
Published 2004
Pbfree Code yes
Termination Solder
Connector Type FFC/FPC CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Receptacle
Additional Feature ZIF
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 50V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 500μm
Orientation Right Angle
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.732 inch
Number Of PCB Rows 1
Lead Pitch 500μm
Number of Contacts 24
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
UL Flammability Code 94V-0
Rated Current (Signal) 0.5A
Contact Style DUAL PRONG
Contact Resistance 20mOhm
Insulation Resistance 50MOhm
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Flat Flex
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Contact Location Bottom
Dimensions
Plating Thickness 39μin
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
