52435-3072
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FFC TOP 30POS 0.50MM R/A
PDF
/
Buying Options
Total Price: USD $1.91
Unit Price: USD $1.914164
≥1 USD $1.914164
≥10 USD $1.805813
≥100 USD $1.703592
≥500 USD $1.607168
≥1000 USD $1.516191
Inventory: 5523
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Contact Plating Tin
Mount Surface Mount
Housing Material Nylon
Actuator Material Polyphenylene
Technical
Packaging Tape & Reel
Published 2007
Termination Solder
Connector Type FFC/FPC CONNECTOR
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Receptacle
Additional Feature ZIF
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 50V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 500μm
Orientation Right Angle
Current Rating 500mA
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.85 inch
Number Of PCB Rows 1
Lead Pitch 500μm
Number of Contacts 30
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
UL Flammability Code 94V-0
Rated Current (Signal) 0.5A
Contact Style DUAL PRONG
Contact Resistance 20mOhm
Insulation Resistance 50MOhm
Dielectric Withstanding Voltage 250VAC V
Wire/Cable Type Straight
Durability 20 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Insulator Color NATURAL
Contact Location Top
Dimensions
Plating Thickness 39μin
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
