5034801840
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
BackFlip Easy-On 503480 ROHS3Compliant 2014 Right Angle FFC, FPC (Connector/Contact Type) Connector UL94V-0 -40C~85C 500mA 50V
PDF
/
Inventory: 8047
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.039 1.00mm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Actuator Color Black
Locking Feature Flip Lock, Backlock
Cable End Type Straight or Tapered
Connector/Contact Type Contacts, Top and Bottom
Flat Flex Type FFC, FPC
Halogen Free Low Halogen
Mating Cycles 10
Wire/Cable Type Straight
Housing Color White
Contact Finish Gold
Current Rating 500mA
Reach Compliance Code unknown
Orientation Right Angle
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 18
Connector Type FFC/FPC CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention
Series BackFlip, Easy-On 503480
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyamide (PA), Nylon, Glass Filled
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Phosphor Bronze
