5033668011
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 503366 ROHS3Compliant 2012 Flip Lock FFC, FPC (Connector/Contact Type) Connector -20C~85C 0.5A 50V 0.30mm
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5752
≥1 USD $1.5752
≥10 USD $1.5048
Inventory: 7700
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Published 2012
Series Easy-On 503366
Feature Solder Retention
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type CARD EDGE CONNECTOR
Number of Positions 80
Voltage - Rated 50V
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Contact Finish Gold
Housing Color Black
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tabbed, Tapered
Locking Feature Flip Lock
Dimensions
Height Above Board 0.079 2.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
