5025981793
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6864
≥1 USD $0.6864
Inventory: 8874
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Option 1 LOCKING
Actuator Material Polyamide (PA), Nylon, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2014
Series BackFlip, Easy-On 502598
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 17
Number of Rows 1
Voltage - Rated 50V
Subcategory Headers and Edge Type Connectors
Current Rating (Amps) 0.2A
Pitch 0.012 0.30mm
Total Number of Contacts 17
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.283 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Body Breadth 0.045 inch
Housing Color White
Body Depth 0.15 inch
Contact Style SQ PIN-SKT
Contact Resistance 60mOhm
Insulation Resistance 50000000Ohm
Contact Pattern RECTANGULAR
Mating Cycles 10
Insulator Color NATURAL
Flat Flex Type FPC
Connector/Contact Type Contacts, Top and Bottom
Cable End Type Tapered
Locking Feature Flip Lock, Backlock
Actuator Color Black
Dimensions
Contact Finish Thickness 3.94μin 0.10μm
Plating Thickness 3.93μin
Height Above Board 0.045 1.14mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
