5023503900
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors 0.3 FPC Hsg Assy 39Ckt EmbsTp Pkg
PDF
/
Inventory: 5321
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2012
Series BackFlip, Easy-On 502350
Feature Solder Retention
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 39
Number of Rows 1
Subcategory Headers and Edge Type Connectors
Current Rating (Amps) 0.3A
Pitch 0.012 0.30mm
Orientation Right Angle
Depth 4.72mm
Current Rating 300mA
Reference Standard UL
Contact Finish Gold
Voltage - Rated AC 50V
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 39
PCB Contact Pattern STAGGERED
Body Breadth 0.043 inch
Housing Color White
Contact Style BELLOWED TYPE
Max Voltage Rating (AC) 50V
PCB Contact Row Spacing 3.3528 mm
Contact Pattern RECTANGULAR
Mating Cycles 10
Flat Flex Type FPC
Connector/Contact Type Contacts, Top and Bottom
Cable End Type Tapered
Locking Feature Flip Lock, Backlock
Actuator Color Black
Dimensions
Length 13.6mm
Height Above Board 0.044 1.12mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
