5020783960
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 502078 ROHS3Compliant COMMERCIAL UL FPC (Connector/Contact Type) Connector 80mOhm -20C~85C 0.2A 50V
PDF
/
Inventory: 8928
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP)
Mounting Option 1 LOCKING
Actuator Material Polyamide (PA), Nylon
Board Mounting Option FITTING NAIL
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Published 2013
Series Easy-On 502078
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 39
Number of Rows 1
Voltage - Rated 50V
Additional Feature BOTTOM CONTACT STYLE, EASY-ON, POLARIZED
HTS Code 8536.69.40.51
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.2A
Pitch 0.010 0.25mm
Total Number of Contacts 39
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.453 inch
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Contact Gender FEMALE
Housing Color Beige
Contact Style BELLOWED TYPE
Contact Resistance 80mOhm
Insulation Resistance 50000000Ohm
PCB Contact Row Spacing 2.413 mm
Contact Pattern RECTANGULAR
Mating Cycles 10
Flat Flex Type FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Tapered
Locking Feature Flip Lock
Actuator Color Black
Dimensions
Contact Finish Thickness 3.94μin 0.10μm
Height Above Board 0.039 1.00mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0, UL94 HB
RoHS Status ROHS3 Compliant
