5016161975
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
CONN FPC TOP 19POS 0.30MM R/A
PDF
/
Inventory: 7959
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.20mm
Height Above Board 0.044 1.12mm
Length 7.6mm
Technical
Contact Location Top
Glow Wire Compliant Non-compliant
Stackable No
Actuator Color Gray
Locking Feature Flip Lock, Backlock
Cable End Type Tapered
Connector/Contact Type Contacts, Top
Flat Flex Type FPC
Mating Cycles 10
Withdrawl Force-Min ZIF N
Insertion Force-Max ZIF N
Contact Pattern RECTANGULAR
Wire/Cable Type Straight
Max Voltage Rating (AC) 50V
ELV Compliant
Insulation Resistance 50000000Ohm
Contact Resistance 80mOhm
Contact Style BELLOWED TYPE
Housing Color Black
UL Flammability Code 94V-0
Body Breadth 0.043 inch
PCB Contact Pattern STAGGERED
Number of Contacts 19
Number Of PCB Rows 2
Reliability COMMERCIAL
Voltage - Rated AC 50V
Contact Finish Gold
Reference Standard UL
Current Rating 200mA
Depth 3.45mm
Orientation Right Angle
Pitch 0.012 0.30mm
Current Rating (Amps) 0.2A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.51
Additional Feature EAZY-ON, ZIF
Gender Receptacle
Number of Rows 2
Number of Positions 19
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Solder Retention, Zero Insertion Force (ZIF)
Series Easy-On 501616
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Mounting Option 1 LOCKING
Housing Material Polymer
Mounting Type Surface Mount, Right Angle
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
