39-53-2174
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors 1.25MM 17P RA CONN ZIF THRU-HOLE
PDF
/
Buying Options
Total Price: USD $68.43
Unit Price: USD $1.052794
≥65 USD $1.052794
≥350 USD $1.001308
≥650 USD $0.971505
≥1300 USD $0.930915
≥2400 USD $0.902181
Inventory: 4431
Minimum: 65
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Bronze
Contact Plating Tin
Mounting Type BOARD
Housing Material PBT
Mounting Option 1 LOCKING
Actuator Material PBT, Polybutylene, Polyester
Technical
Published 2009
Pbfree Code yes
Part Status Active
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 17
Max Operating Temperature 80°C
Min Operating Temperature -20°C
Number of Rows 1
Gender Female
Voltage - Rated 200V
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 1.25mm
Total Number of Contacts 17
Orientation Right Angle, Vertical
Current Rating 1A
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 1.25mm
PCB Contact Pattern STAGGERED
UL Flammability Code 94V-0
Body Depth 0.386 inch
Contact Style BELLOWED TYPE
Contact Resistance 20mOhm
Wire/Cable Type Straight
PCB Contact Row Spacing 5.0038 mm
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Stackable No
Contact Location Top
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
