15-47-4173
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors SL FFC/FPC Opt G Fem 15 SAu 17Ckt
PDF
/
Inventory: 9368
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mount Free Hanging
Housing Material Polyester
Technical
Published 2012
Pbfree Code yes
Part Status Active
Termination IDC
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 17
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Female
Voltage - Rated 250V
Additional Feature SL
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 17
Orientation Vertical
Current Rating 2A
Reference Standard UL, CSA
Reliability COMMERCIAL
Lead Pitch 2.54mm
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Body Depth 0.6 inch
Rated Current (Signal) 2A
Contact Style SQ PIN-SKT
Body/Shell Style PLUG
Polarization Key POLARIZED RIB(S)
Wire/Cable Type Straight
Durability 50 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 2.224 N
Withdrawl Force-Min .278 N
Contact Design PREASSEM CONN
Dimensions
Height 15.2mm
Length 43.2mm
Width 2.51mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
