1040839617
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC Connector
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9624
≥1 USD $1.9624
≥10 USD $1.892
Inventory: 15070
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.059 1.50mm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Actuator Color Black
Locking Feature Flip Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FFC, FPC
Contact Pattern RECTANGULAR
Housing Color Natural
PCB Contact Pattern RECTANGULAR
Reliability COMMERCIAL
Contact Finish Gold
Total Number of Contacts 96
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A per Contact
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.51
Voltage - Rated 50V
Number of Rows 1
Number of Positions 96
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Solder Retention, Zero Insertion Force (ZIF)
Series 104083
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Actuator Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Option 1 LOCKING
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 6 Weeks
