0905004019
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
90500 ROHS3Compliant Slide Lock Zero Insertion Force (ZIF) FFC (Connector/Contact Type) Connector -40C~85C 2.5A 250V 0.20mm
PDF
/
Inventory: 6576
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.20mm
Height Above Board 0.285 7.24mm
Technical
Locking Feature Slide Lock
Cable End Type Notched
Connector/Contact Type Contacts, Top and Bottom
Flat Flex Type FFC
Mating Cycles 50
Housing Color Black
Contact Finish Tin
Pitch 0.100 2.54mm
Current Rating (Amps) 2.5A
Voltage - Rated 250V
Number of Positions 19
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Zero Insertion Force (ZIF)
Series 90500
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Polybutylene Terephthalate (PBT), Glass Filled
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
