0905004009
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
90500 ROHS3Compliant Slide Lock Zero Insertion Force (ZIF) FFC (Connector/Contact Type) Connector -40C~85C 2.5A 250V 0.20mm
PDF
/
Inventory: 1626
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Actuator Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series 90500
Feature Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 9
Voltage - Rated 250V
Current Rating (Amps) 2.5A
Pitch 0.100 2.54mm
Contact Finish Tin
Housing Color Black
Mating Cycles 50
Flat Flex Type FFC
Connector/Contact Type Contacts, Top and Bottom
Cable End Type Notched
Locking Feature Slide Lock
Dimensions
Height Above Board 0.285 7.24mm
FFC, FCB Thickness 0.20mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
