0781271288
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 28 POS 1mm Solder ST SMD Easy-On? T/R
PDF
/
Inventory: 1872
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 78127
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 28
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.51
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 28
Contact Finish Gold
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Natural
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered
Dimensions
Contact Finish Thickness 3.94μin 0.10μm
Height Above Board 0.161 4.10mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
