0781271249

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FFC & FPC Connectors 0.5 FPC CONN. VERTIC AL SMT NON-ZIF 24CKT
PDF
/
Inventory: 4274
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 78127
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 24
Number of Rows 1
Voltage - Rated 50V
HTS Code 8536.69.40.51
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 24
Contact Finish Tin Bismuth
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Natural
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered

Dimensions

Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.161 4.10mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
