0781271179
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FPC Connector SKT 17 POS 1mm Solder ST SMD Easy-On? Embossed T/R
PDF
/
Inventory: 4451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.161 4.10mm
Contact Finish Thickness 39.4μin 1.00μm
Length 10.6mm
Technical
Cable End Type Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Mating Cycles 20
Contact Pattern RECTANGULAR
Max Voltage Rating (AC) 50V
Insulation Resistance 50000000Ohm
Contact Resistance 30mOhm
Housing Color Natural
PCB Contact Pattern RECTANGULAR
Number of Contacts 17
Reliability COMMERCIAL
Contact Finish Tin Bismuth
Reference Standard UL, CSA
Current Rating 500mA
Depth 2.95mm
Orientation Vertical
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Number of Positions 17
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 78127
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
