0781192910
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 78119 RoHS Compliant Tin Bismuth Solder FFC, FPC (Connector/Contact Type) Connector -40C~85C 0.5A 50V 39.4muin 1.00mum
PDF
/
Inventory: 965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.161 4.10mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Cable End Type Tabbed, Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Mating Cycles 10
Housing Color Black
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 29
Connector Type FFC/FPC CONNECTOR
Termination Solder
Part Status Active
Series Easy-On 78119
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 12 Weeks
