0781191408

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description Conn FFC/FPC Connector RCP 40 POS 0.5mm Solder ST SMD Easy-On? Embossed T/R
PDF
/
Inventory: 8152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.30mm
Height Above Board 0.161 4.10mm
Contact Finish Thickness 3.94μin 0.10μm

Technical

Cable End Type Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Mating Cycles 20
Housing Color Natural
UL Flammability Code 94V-0
Contact Gender FEMALE
Contact Finish Gold
Total Number of Contacts 40
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 50V
Number of Rows 1
Number of Positions 40
Connector Type FFC/FPC CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 78119
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Surface Mount
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 12 Weeks
