0781191349
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
78119 ROHS3Compliant Vertical GENERAL PURPOSE FFC, FPC (Connector/Contact Type) Connector UL94V-0 30mOhm -40C~85C 500mA
PDF
/
Inventory: 1385
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.161 4.10mm
Contact Finish Thickness 39.4μin 1.00μm
Length 19.1mm
Technical
Cable End Type Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FFC, FPC
Mating Cycles 20
Max Voltage Rating (AC) 50V
Contact Resistance 30mOhm
Housing Color Natural
UL Flammability Code 94V-0
Contact Gender FEMALE
Number of Contacts 34
Contact Finish Tin Bismuth
Current Rating 500mA
Depth 2.95mm
Orientation Vertical
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Number of Positions 34
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 78119
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Nickel, Tin
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 11 Weeks
