0781191348
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FFC/FPC Connector SKT 34 POS 0.5mm Solder ST SMD Embossed T/R
PDF
/
Inventory: 6569
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 78119
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 34
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 34
Orientation Vertical
Depth 2.95mm
Current Rating 500mA
Contact Finish Gold
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Natural
Contact Resistance 30mOhm
Number of Circuits 33
Max Voltage Rating (AC) 50V
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered
Dimensions
Length 19.1mm
Contact Finish Thickness 3.94μin 0.10μm
Height Above Board 0.161 4.10mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
