0781191088

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description Conn FFC/FPC Connector SKT 8 POS 0.5mm Solder ST SMD Embossed T/R
PDF
/
Inventory: 5667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper Alloy
Mounting Type Surface Mount
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 78119
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type FFC/FPC CONNECTOR
Number of Positions 8
Number of Rows 1
Voltage - Rated 50V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 8
Contact Finish Gold
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color Natural
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered

Dimensions

Contact Finish Thickness 3.94μin 0.10μm
Height Above Board 0.161 4.10mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
