0545481933
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 54548 ROHS3Compliant Slide Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~85C 50V 39.4muin 1.00mum
PDF
/
Inventory: 3533
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.047 1.20mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Actuator Color Black
Locking Feature Slide Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FFC, FPC
Mating Cycles 20
Housing Color White
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
HTS Code 8536.69.40.51
Voltage - Rated 50V
Number of Positions 19
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Solder Retention, Zero Insertion Force (ZIF)
Series Easy-On 54548
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
