0545481533
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 54548 ROHS3Compliant Slide Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~85C 50V 39.4muin 1.00mum
PDF
/
Inventory: 2070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 54548
Feature Solder Retention, Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 15
Voltage - Rated 50V
HTS Code 8536.69.40.51
Pitch 0.020 0.50mm
Contact Finish Tin Bismuth
Housing Color White
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight, Tapered
Locking Feature Slide Lock
Actuator Color Black
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.047 1.20mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
