0545481433
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 54548 ROHS3Compliant Slide Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~85C 50V 39.4muin 1.00mum
PDF
/
Inventory: 5404
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.047 1.20mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Actuator Color Black
Locking Feature Slide Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FFC, FPC
Mating Cycles 20
Housing Color White
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
Voltage - Rated 50V
Number of Positions 14
Connector Type FFC/FPC CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Solder Retention, Zero Insertion Force (ZIF)
Series Easy-On 54548
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Liquid Crystal Polymer (LCP), Glass Filled
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 18 Weeks
