0545480970
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 54548 ROHS3Compliant Flip Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~85C 0.5A 50V 8.00muin 0.203mum
PDF
/
Inventory: 9455
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Liquid Crystal Polymer (LCP)
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 54548
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 9
Voltage - Rated 50V
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Contact Finish Tin Bismuth
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight, Tapered
Locking Feature Flip Lock
Dimensions
Contact Finish Thickness 8.00μin 0.203μm
Height Above Board 0.047 1.20mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
