0541043431
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
54104 ROHS3Compliant COMMERCIAL UL FFC, FPC (Connector/Contact Type) Connector ZIF N -20C~85C 0.5A 50V
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
≥10 USD $1.59808
≥100 USD $1.278904
Inventory: 4876
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Option 1 LOCKING
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Board Mounting Option FITTING NAIL
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Series 54104
JESD-609 Code e4
Feature Solder Retention, Zero Insertion Force (ZIF)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type FFC/FPC CONNECTOR
Number of Positions 34
Number of Rows 1
Voltage - Rated 50V
Additional Feature EASY-ON, POLARIZED
HTS Code 8536.69.40.51
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 34
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.886 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Housing Color White
Body Depth 0.22 inch
Contact Style SINGLE PRONG
Insulation Resistance 50000000Ohm
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Straight, Tapered
Locking Feature Slide Lock
Actuator Color Brown
Dimensions
Contact Finish Thickness 3.94μin 0.10μm
Height Above Board 0.079 2.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
