0528932295

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description Conn FPC Connector SKT 22 POS 0.5mm Solder RA SMD Easy-On? Embossed T/R
PDF
/
Inventory: 5188
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm
Contact Finish Thickness 39.4μin 1.00μm

Technical

Actuator Color Brown
Locking Feature Flip Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FFC, FPC
Mating Cycles 20
Housing Color White
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 22
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Solder Retention, Zero Insertion Force (ZIF)
Series Easy-On 52893
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C

Physical

Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 27 Weeks
