0528931533
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 52893 ROHS3Compliant Flip Lock Solder Retention Zero Insertion Force (ZIF) FPC (Connector/Contact Type) Connector -40C~85C 0.5A 50V 39.4muin 1.00mum
PDF
/
Inventory: 8854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Actuator Color Brown
Locking Feature Flip Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FPC
Mating Cycles 20
Housing Color White
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
HTS Code 8536.69.40.51
Voltage - Rated 50V
Number of Positions 15
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Solder Retention, Zero Insertion Force (ZIF)
Series Easy-On 52893
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Polyamide (PA), Nylon
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 28 Weeks
