0528921696
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
0.5 FFC/FPC ZIF HSG ASSY 16CKT E
PDF
/
Inventory: 3441
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Locking Feature Flip Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Bottom
Flat Flex Type FFC, FPC
Mating Cycles 20
Contact Gender FEMALE
Contact Finish Gold
Total Number of Contacts 16
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 50V
Number of Rows 1
Number of Positions 16
Connector Type FFC/FPC CONNECTOR
Termination Solder
Part Status Active
Pbfree Code yes
Feature Solder Retention
JESD-609 Code e4
Series Easy-On 52892
Packaging Tape & Reel (TR)
Operating Temperature -30°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS)
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 21 Weeks
