0528522570

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description Conn FFC Connector SKT 25 POS 1mm Solder RA SMD Easy-On? T/R
PDF
/
Inventory: 6632
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyphenylene Sulfide (PPS)

Technical

Operating Temperature -20°C~80°C
Packaging Tape & Reel (TR)
Series Easy-On 52852
Feature Solder Retention
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 25
Voltage - Rated 50V
Current Rating (Amps) 0.5A
Pitch 0.039 1.00mm
Contact Finish Tin Bismuth
Mating Cycles 10
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight

Dimensions

Height Above Board 0.122 3.10mm
FFC, FCB Thickness 0.30mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
