0527461170
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 52746 ROHS3Compliant COMMERCIAL UL CSA FFC, FPC (Connector/Contact Type) Connector ZIF N -20C~85C 0.5A 50V
PDF
/
Inventory: 977
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Total Number of Contacts 11
Reference Standard UL, CSA
Contact Finish Tin Bismuth
Reliability COMMERCIAL
Body Length or Diameter 0.457 inch
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.079 inch
Contact Gender FEMALE
UL Flammability Code 94V-0
Body Depth 0.197 inch
Contact Style BELLOWED TYPE
Insulation Resistance 50000000Ohm
Contact Pattern RECTANGULAR
Insertion Force-Max ZIF N
Withdrawl Force-Min ZIF N
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight
Locking Feature Slide Lock
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.51
Voltage - Rated 50V
Number of Rows 1
Number of Positions 11
Connector Type FFC/FPC CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Solder Retention, Zero Insertion Force (ZIF)
JESD-609 Code e6
Series Easy-On 52746
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Dimensions
Height Above Board 0.079 2.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Physical
Board Mounting Option FITTING NAIL
Actuator Material Polyphenylene Sulfide (PPS)
Mounting Option 1 LOCKING
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
