0527451290
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
52745 Non-RoHS Compliant Slide Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -20C~85C 0.5A 50V 0.30mm
PDF
/
Inventory: 6762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm
Technical
Actuator Color Black
Locking Feature Slide Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Top
Flat Flex Type FFC, FPC
Mating Cycles 20
Housing Color White
Contact Finish Tin-Lead
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 12
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention, Zero Insertion Force (ZIF)
Series 52745
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Housing Material Polyamide (PA46), Nylon 4/6, Glass Filled
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
