0526891587
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Conn FFC/FPC Connector SKT 15 POS 0.5mm Solder RA SMD Easy-On? Embossed T/R
PDF
/
Inventory: 1589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm
Contact Finish Thickness 39.4μin 1.00μm
Technical
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Top and Bottom
Flat Flex Type FFC, FPC
Mating Cycles 20
Contact Finish Tin Bismuth
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 15
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention
Series 52689
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
