0526101490
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 52610 Non-RoHS Compliant Vertical Slide Lock FPC (Connector/Contact Type) Connector -20C~85C 500mA 125V 0.30mm
PDF
/
Inventory: 9889
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
FFC, FCB Thickness 0.30mm
Height Above Board 0.226 5.74mm
Technical
Locking Feature Slide Lock
Cable End Type Tapered
Connector/Contact Type Contacts, Vertical - 1 Sided
Flat Flex Type FPC
Insulation Resistance 100MOhm
Number of Contacts 14
Lead Pitch 1mm
Contact Finish Tin
Current Rating 500mA
Orientation Vertical
Pitch 0.039 1.00mm
Current Rating (Amps) 1A
Voltage - Rated DC 125V
Gender Female
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Zero Insertion Force (ZIF)
Series Easy-On 52610
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Physical
Actuator Material Polyphenylene Sulfide (PPS)
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount
Contact Material Phosphor Bronze
