0526100934
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
ZIF FFC Connector
PDF
/
Inventory: 8045
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount
Housing Material Polyamide (PA), Nylon, Glass Filled
Actuator Material Polyphenylene Sulfide (PPS), Glass Filled
Technical
Packaging Tape & Reel (TR)
Series Easy-On 52610
Feature Zero Insertion Force (ZIF)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 9
Number of Rows 1
Additional Feature ZIF
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Total Number of Contacts 9
Contact Finish Tin Bismuth
Contact Gender FEMALE
Housing Color White
Flat Flex Type FPC
Connector/Contact Type Contacts, Vertical - 1 Sided
Cable End Type Tapered
Locking Feature Slide Lock
Actuator Color Brown
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.226 5.74mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
