0524373091
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
FFC & FPC Connectors RA SMT ZIF BOTTOM 30 bottom contact style
PDF
/
Inventory: 2503
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -20°C~85°C
Packaging Tape & Reel (TR)
Series 52437
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 30
Number of Rows 1
Gender Receptacle
Voltage - Rated DC 50V
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Orientation Right Angle
Depth 6.3mm
Current Rating 500mA
Contact Finish Tin
Lead Pitch 500μm
Contact Resistance 20mOhm
Insulation Resistance 50MOhm
Max Voltage Rating (AC) 50V
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Bottom
Cable End Type Straight
Locking Feature Flip Lock
Dimensions
Length 21.6mm
Height Above Board 0.079 2.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
