0524353091

Molex
RoHS
/
Package /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description FFC Connector
PDF
/
Inventory: 7137
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

FFC, FCB Thickness 0.30mm
Height Above Board 0.079 2.00mm

Technical

Locking Feature Slide Lock
Cable End Type Straight, Tapered
Connector/Contact Type Contacts, Top
Flat Flex Type FFC, FPC
Mating Cycles 20
Contact Finish Tin-Lead
Pitch 0.020 0.50mm
Current Rating (Amps) 0.5A
Voltage - Rated 50V
Number of Positions 30
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention, Zero Insertion Force (ZIF)
Series 52435
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Actuator Material Polyphenylene Sulfide (PPS)
Housing Material Polyamide (PA46), Nylon 4/6
Mounting Type Surface Mount, Right Angle
Contact Material Phosphor Bronze
