0524353072
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors
Description
Easy-On 52435 ROHS3Compliant Slide Lock Solder Retention Zero Insertion Force (ZIF) FFC, FPC (Connector/Contact Type) Connector -40C~85C 0.5A 50V 39.4muin 1.00mum
PDF
/
Buying Options
Total Price: USD $2.31
Unit Price: USD $2.3144
≥1 USD $2.3144
≥10 USD $1.97208
≥100 USD $1.629144
Inventory: 6031
Minimum: 1
-
+
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Surface Mount, Right Angle
Housing Material Polyamide (PA46), Nylon 4/6
Actuator Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series Easy-On 52435
Feature Solder Retention, Zero Insertion Force (ZIF)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 30
Voltage - Rated 50V
Current Rating (Amps) 0.5A
Pitch 0.020 0.50mm
Contact Finish Tin Bismuth
Mating Cycles 20
Flat Flex Type FFC, FPC
Connector/Contact Type Contacts, Top
Cable End Type Straight, Tapered
Locking Feature Slide Lock
Dimensions
Contact Finish Thickness 39.4μin 1.00μm
Height Above Board 0.079 2.00mm
FFC, FCB Thickness 0.30mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
